The Latest Updated: SFP Modules for Cisco Catalyst 2960-X Series Switches

January 12 2018 , Written by Cisco & Cisco Router, Network Switch Published on #Cisco Switches - Cisco Firewall, #Cisco & Cisco Network, #Cisco Modules & Cards, #Networking

We are so familiar with the hot Catalyst 2960-X series, and what are the SFP Transceiver Models for 2960 X Series? Check the table below about the latest SFP models for 2960 X Series.

Catalyst 2960 X Series

Network Device

Transceiver Model

Minimum Software Release Required

DOM Support

Software Release

WS-C2960X-24TS-LL
WS-C2960X-48TS-LL

GLC-LH-SMD
GLC-SX-MMD
GLC-EX-SMD1
GLC-T
GLC-TE
GLC-LH-SM
GLC-SX-MM
GLC-GE-100FX

15.0(2)EX

15.0(2)EX

WS-C2960X-24PSQ-L

GLC-BX-D
GLC-BX-U
GLC-LH-SMD
GLC-SX-MMD
GLC-EX-SMD1
GLC-ZX-SMD
GLC-T
GLC-TE
GLC-ZX-SM
GLC-LH-SM
GLC-SX-MM

15.0(2)EX

15.0(2)EX

WS-C2960X-24PS-L
WS-C2960X-24TS-L
WS-C2960X-48TS-L
WS-C2960X-48LPS-L
WS-C2960X-48FPS-L
WS-C2960X-24TD-L
WS-C2960X-24PD-L
WS-C2960X-48TD-L
WS-C2960X-48LPD-L
WS-C2960X-48FPD-L

GLC-BX-D
GLC-BX-U
GLC-LH-SMD
GLC-SX-MMD
GLC-EX-SMD1
GLC-ZX-SMD
GLC-T
GLC-TE
GLC-ZX-SM
GLC-LH-SM
GLC-SX-MM
CWDM-SFP
GLC-GE-100FX

15.0(2)EX

15.0(2)EX



SFP Transceivers

Model Number

Transceiver Description

GLC-T=

1000BASE-T SFP transceiver module for Category 5 copper wire, RJ-45 connector

GLC-TE=

1000BASE-T SFP transceiver module for Category 5 copper wire, RJ-45 connector, Extended Temperature

GLC-SX-MM=

1000BASE-SX SFP transceiver module for MMF, 850-nm wavelength, dual LC/PC connector

GLC-LH-SM=

1000BASE-LX/LH SFP transceiver module for MMF and SMF, 1300-nm wavelength, dual LC/PC connector

GLC-ZX-SM=

1000BASE-ZX SFP transceiver module for SMF, 1550-nm wavelength, dual LC/PC connector

GLC-BX-D=

1000BASE-BX10 SFP module for single-strand SMF, 1490-nm TX/1310-nm RX wavelength, single LC/PC connector

GLC-BX-U=

1000BASE-BX10 SFP module for single-strand SMF, 1310-nm TX/1490-nm RX wavelength, single LC/PC connector

GLC-BX40-D-I

1000BASE-BX10 SFP module for single-strand SMF, 1550-nm TX/1310-nm RX wavelength, single LC/PC connector

GLC-BX40-U-I

1000BASE-BX10 SFP module for single-strand SMF, 1310-nm TX/1550-nm RX wavelength, single LC/PC connector

GLC-BX80-D-I

1000BASE-BX10 SFP module for single-strand SMF, 1570-nm TX/1490-nm RX wavelength, single LC/PC connector

GLC-BX80-U-I

1000BASE-BX10 SFP module for single-strand SMF, 1490-nm TX/1570-nm RX wavelength, single LC/PC connector

GLC-BX40-DA-I

1000BASE-BX10 SFP module for single-strand SMF, 1490-nm TX/1310-nm RX wavelength, single LC/PC connector

GLC-2BX-D=

Dual-channel 1000BASE-BX10 SFP module for single-strand SMF, 1490-nm TX/1310-nm RX wavelength, two single LC/PC connectors

SFP-GE-S=

1000BASE-SX SFP transceiver module for MMF, 850-nm wavelength, extended operating temperature range and DOM support, dual LC/PC connector

SFP-GE-L=

1000BASE-LX/LH SFP transceiver module for MMF and SMF, 1300-nm wavelength, extended operating temperature range and DOM support, dual LC/PC connector

GLC-EX-SMD=

1000BASE-EX SFP transceiver module for SMF, 1310-nm wavelength, extended operating temperature range and DOM support, dual LC/PC connector

SFP-GE-Z=

1000BASE-ZX SFP transceiver module for SMF, 1550-nm wavelength, extended operating temperature range and DOM support, dual LC/PC connector

SFP-GE-T=

1000BASE-T SFP transceiver module for Category 5 copper wire, extended operating temperature range, RJ-45 connector

GLC-SX-MM-RGD

1000BASE-SX SFP transceiver module for MMF, 850-nm wavelength, industrial Ethernet, dual LC/PC connector

GLC-LX-SM-RGD

1000BASE-LX/LH SFP transceiver module for MMF and SMF, 1300-nm wavelength, industrial Ethernet, dual LC/PC connector

GLC-ZX-SM-RGD

1000BASE-ZX SFP transceiver module for SMF, 1550-nm wavelength, industrial Ethernet, dual LC/PC connector

GLC-SX-MMD=

1000BASE-SX SFP transceiver module for MMF, 850-nm wavelength, extended operating temperature range and DOM support, dual LC/PC connector

GLC-LH-SMD=

1000BASE-LX/LH SFP transceiver module for MMF and SMF, 1300-nm wavelength, extended operating temperature range and DOM support, dual LC/PC connector

GLC-ZX-SMD=

1000BASE-ZX SFP transceiver module for SMF, 1550-nm wavelength, dual LC/PC connector

SFP-GPON-B

Gigabit passive optical network (GPON) Class B+ SFP OLT transceiver module, 1490-nm TX/1310-nm RX wavelength

SFP-GPON-B-I

Gigabit passive optical network (GPON) Class B+ SFP OLT transceiver module, 1490-nm TX/1310-nm RX wavelength, industrial temperature range

SFP-GPON-C

Gigabit passive optical network (GPON) Class C+ SFP OLT transceiver module, 1490-nm TX/1310-nm RX wavelength

SFP-GPON-C-I

Gigabit passive optical network (GPON) Class C+ SFP OLT transceiver module, 1490-nm TX/1310-nm RX wavelength, industrial temperature range

1CPN 10-2624-01 or later only.

The full data sheet of Cisco Gigabit Ethernet Transceiver Modules Compatibility Matrix you can visit here:

https://www.cisco.com/c/en/us/td/docs/interfaces_modules/transceiver_modules/compatibility/matrix/GE_Tx_Matrix.html
